| Model Product Model | HC6001 |
| Output shaft diameter | 19.05mm |
| Maximum wheel diameter | 20 inches |
| Maximum rear axle loading weight | 205kg |
| Maximum Load | 250kg |
| Continuous torque | 200N.M |
| Maximum braking torque | 339N.M |
| Input speed | 1550rpm |
| Service life | 350h |
| Disc brake clearance | 0.5±0.13 |
| Transmission ratio i (reduction ratio) |
63.05/47.71/20.45 /16.07/REVERSE 40.9 |
| Gear adjustment |
Fork shift adjustment: forward (1-2-3-4), neutral, reverse |
| Forward speed |
Vmax=8.5km/h (Speed 1600rpm, 20 ″ wheels) Vmin=2.15 |
| Reverse speed |
Vmax=3.2km/ h(Speed 1600rpm, 20 ″ wheels) |
* Weight limitation for reference only. The final weight is up to your customized model.
